機型

1247L

規格

后裝開架式

外殼/邊框顏色

鐵件/黑色小型外框

顯示器尺寸

12.1"

長寬比例

4:3

顯示區域

水平: 9.7" (246 mm)
垂直: 7.3" (185 mm)

顯示器尺寸

寬: 11.9" (303 mm)
高: 9.5" (242 mm)
厚: 2.4" (60 mm)

最佳（真實）分辨率

800 x 600 at 60 Hz

其它支持分辨率

800 x 600 at 56, 60, 72 or 75 Hz
720 x 400 at 70 Hz
640 x 480 at 60, 66 Hz (Mac), 72 or 75 Hz
640 x 350 at 70 Hz

顏色

262,000

亮度

LCD 面板: 350 nits
表面聲波屏: 320 nits

響應時間

40 msec

視角

水平: ±65° or 130° total
垂直: 65°/40° or 105° total

對比度（標準值）

500:1

輸入視頻模式

Analog VGA

輸入視頻信號連接器

Mini D-Sub 15-Pin VGA type

輸入頻率

水平: 31.5-48.1 kHz
垂直: 56.3-75 Hz

電源

External DC (power brick)

輸入電壓

DC: 12 volts at 3.33 amps max

Input connector

DC: Coaxial power jack (2 mm pin diameter, 6.4 mm barrel diameter, 8.8 mm barrel length)

功耗

11.98 W

溫度

工作: 0°C to 40°C (32°F to 104°F)
儲藏: -20°C to 60°C (-4°F to 140°F)

濕度

工作: 20%-85%
儲藏: 5%-95%

重量

實重: 8.8 lb (4.0 kg)
運輸: 13.2 lb (6.0 kg)

運輸尺寸
(W x D x H)

17.32" (440 mm) x 12.80" (325 mm) x 7.68" (195 mm)

背光燈壽命

Typical 50,000 hours to half 亮度

MTBF

50,000 hours demonstrated

保修

3 年

Optional product coverage

Extended 保修 (North America and EMEA only)

認證

UL/cUL (*recognized component), FCC, TÜV-Bauart, CE, VCCI, C-Tick

OSD按鈕

Controls (remote with 1.8m cable): menu, down, up, auto/sel
Settings: contrast, 亮度, V/H position, recall default, RGB, OSD exit, sharpness, phase, clock, OSD H/V position, OSD time, auto adjust, information
Languages: English, French, German, Spanish, Japanese
Lockouts: power, user controls

安裝選擇

75 mm VESA mount
Rear mount through bezel or with included standard mounting brackets
Rack mount option

其它特性

Energy save mode (less than 2 watts)
2 stage DPMS
VESA DDC Plug and Play
